LED Unit
LED Unit
Head Cover
Body
■Removal
While holding the LED unit, turn the head cover counterclockwise
until it unlocks, then pull it upwards to remove.
< Head Cover to LED Unit >
■Attachment
Align the Positioning Mark after insertion, then turn the unit
clockwise to lock it.
<Locked>
<Unlocked>
■Positioning Mark
<Unlocked>
■
Positioning Mark
<Locked>
Align the Positioning Mark
after inserting.
