42
<Unit Replacement Procedure>
■Decreasing the LED Units
Remove the LED unit located above the unit
which is intended to be removed.
1
While holding the LED unit, turn the LED unit
counterclockwise,until it unlocks, then pull it
upwards to remove.
2
Align the Positioning Mark after insertion,
then turn the unit which is removed ( 1 )
clockwise to lock it.
3
