44
■Recombining the LED Units
Remove the LED unit located above the
unit which is intended to be relocated.
1
While holding the LED unit, turn the LED
unit counterclockwise until it unlocks, then
pull it upwards to remove.
2
4
Remove the LED unit located above the
unit which is intended to be relocated.
3
Align the Positioning Mark after insertion,
then turn the unit which is removed ( 2 )
clockwise to lock it.
