48
LED Unit Underside View
LED Unit Topside View
(Attachable)
Lens
Lens
Tab is placed in the groove.
Tab is placed in the groove.
Turn the internal lens of the LED Unit counterlockwise until
the tab fits in the groove.
Attach the LED Unit to the product.
If the LED Unit can’t be attached, try the procedure below.
