Patlite LR4 - Page 58

58
LR4:∅40 , LR5:∅50
LR6:∅60 , LR7:∅70
53.5
LR5
・
7
OuterDimensions
Model Number Configuration
EMC Directive (EN 61000-6-4, EN 61000-6-2)
RoHS Directive (EN 50581)
GeneralSpecifications
LR7
LR6
LR5
LR4
LR7
LR6
LR5
LR4
B
LR
[
4/5/6/7
]
- B [W/U/K]
Buzzer Unit
Buzzer Unit
↓↓
LR -
Model
K
Black
※1
U
Silver
W
Body Color
4
5
Φ
40
Φ
50
6
7
Φ
60
Φ
70
UL508, CSA-C22.2 N
FCC Part 15 Subpart B Class A
Conformity Standards
Model
LR□-B□
Typ.85dB
Typ.85dB (※Typ.80dB)
Typ.88dB
Typ.90dB
Buzzer sound No.4 was measured from the total
circumference of the buzzer Unit at 1m
Sound Pressure Level
Remarks ※ When LR5-01 (12V DC type) is attached.
Environmental
Condition
Buzzer Sound/
Typical Frequency
No.1
No.2
No.3
No.4
Rapid Intermittent Beep/ 3378Hz
Continuous Beep Sound/ 3378Hz
Rapid Hi-Lo/ 2016Hz&3012Hz
Sweep Sound/ 1000Hz-4032Hz
Operating Ambient Temperature
Operating Ambient Humidity
Mass
（Tolerance ±10％）
-20℃ 〜 +50℃
Less than 90% RH (No Condensation)
0.035kg
0.050kg
0.060kg
0.070kg
Off-white
Sound Reduction approx.
-10dB, depending on DIP
Switch settings.
Refer to Section 6 “Buzzer
Pattern Set-up”
※
1

（Unit
:
mm
）
