Patlite LR4 - Page 59

59
Mounting Hole
(φ5×3 places)
Mounting Hole
(φ5×4 places)
φ
54
〜
φ
56
120°
90°
Wire Distribution
Hole (φ12)
(Unit : mm)
Mounting Dimensional Drawing■
SZP-001W
0.6 N m
Recommended Torque
φ
40
〜
φ
50
∅
70
Pole
∅21.7
M4
Screw/Nut
(∅29)
50
(21)
SZP-001W
Accessories:
Waterproof Packing
Pole Waterproof Ring
Binding Head Tapping Screw ( 2 pcs.)
Circular Bracket
Specifications
Protection Rating
Mounting Location
Model
Material
SZP-001W
Remarks
Mass (Tolerance ±10%)
Indoor Only
IP65 (with product attached)
PC
0.04kg
〈Note〉
● It's possible to run a cable out from the side.
(※1)Requiredpoleisnotincludedwith.
Outer Dimensions
Mounting Dimensional Drawing
-
PJ
LR4
-
PJLR5
,
,
POLE22-0100AN,POLE22-0300AN
POLE22-0100ANK,POLE22-0300ANK
QJ
-
PJ
LR6
QJ
Compatible Models
Compatible Pole
※No Accessories
There are no contents of controlled
substances exceeding the threshold
for the RoHS Directive.
（Unit
:
mm
）
KT
-
LR7 KT
※
1
※
1
KT
001
Circular Bracket
↓
SZP -
Model
W
Body Color
Off-white
Model Number Configuration
