81
Flanged nut (3 pcs.)
1. Insert the mounting screws of the product into the Circular Bracket.
See the figure on the left for details on the direction of insertion.
2. Secure the product with the flanged nuts (3 pcs.) from underneath
the Bracket.
Installation using materials other than the specified
accessories is not covered under warranty.
Notice
0.6 N
m
Product Attachment
Recommended Torque
