Patlite LR4 - Page 82

82
(Unit: mm)
Mounting Dimensional Drawing■
SZW-940U
Product Mounting
Hole 3 places
φ42
20
13.5
M3
Maximum Board Thickness : 10
120°
φ30
5
Mounting Hole
(φ4×3 places)
Wire Distribution
Hole (φ12)
0.6 N m
Recommended Torque
M3
Screw/Nut
SZW-940U
Compatible Direct Mount Bracket
Mounting Dimensional Drawing
-
WJ
LR4
-
W
LCE
-
AW
LCE
MountingHoleCompatibleModel
Accessories:
Hexagon Nut with Flange
( 3 pcs.)
Model Number Configuration
940 U
SZW -
U
Silver
Model
Body Color
Compatible Direct Mount Bracket
Compatible Models
Specifications
Protection Rating
Mounting Location
Model
Material
SZW-940U
Remarks
Mass (Tolerance ±10%)
Indoor Only
IP65 (with product attached）
AL
0.04kg
※No Accessories
There are no contents of controlled
substances exceeding the threshold
for the RoHS Directive.
