Patlite LR4 - Page 83

83
■
SZW-950U
φ
30
120°
Wire Distribution
Hole
（
φ
8
〜
φ
13
）
10
〜
12.5
φ50
20
15
M3
(
※
1) Refer to "Product Attachment (SZW-950U Mounting Hole A)"
for using the Mounting Hole A.
(
※
2) Refer to "Product Attachment (SZW-950U Mounting Hole B)"
for using the Mounting Hole B.
Product Mounting
Hole 3 places
Maximum Board Thickness : 10
Mounting Dimensional Drawing
(Unit: mm)
Mounting Hole A
(
φ
4×3 places)
※1
Mounting Hole B
(
φ
5×2 places)
※2
0.6 N m
Recommended Torque
M3
Screw/Nut
(Mountiong Hole A)
M4
Screw
(Mountiong Hole B)
-
WJ WT
LR5
-
W
LE
-
AW
LES
LU5
SZW-950U
Compatible Direct Mount Bracket
Accessories:
Hexagon Nut with Flange
( 3 pcs.)
Model Number Configuration
950 U
SZW -
U
Silver
Model
Body Color
Compatible Direct Mount Bracket
MountingHoleCompatibleModel
Compatible Models
Specifications
Protection Rating
Mounting Location
Model
Material
SZW-950U
Remarks
Mass (Tolerance ±10%)
Indoor Only
IP65 (with product attached）
AL
0.07kg
※No Accessories
There are no contents of controlled
substances exceeding the threshold
for the RoHS Directive.
Mounting Dimensional Drawing
Outer Dimensions
（Unit
:
mm
）
