PAX S80 Setup Guide

PRINTER SET-UP
Press the Up scroll arrow to access the ADMIN MENU
Press 5 for PRINT SET-UP
Set the NUMBER OF COPIES (choose 2 for merchant and customer copy), press OK
Set PAUSE between copies to YES/NO, press OK
If Pause set to YES, set PRINTER INTERVAL in seconds
Set PRINT DECLINED RECEIPTS to YES/NO, press OK (recommended to set to YES)
Set PRINT VOID RECEIPTS to YES/NO, press OK (recommended to set to YES)
Set PRINT COMPLETION to YES/NO, press OK (recommended to set to YES)
Set PRINT FORCED RECEIPTS to YES/NO, press OK (recommended to set to YES)
Set RECEIPT FOOTER: Set up to 4 lines of te xt - 24 characters per line. Press 0 twice for space.
Set FOOTER #1 Enter alpha-numeric for first receipt footer line, press OK
Set FOOTER #2 Enter alpha-numeric for second receipt footer line, press OK
Set FOOTER #3 Enter alpha-numeric for first receipt footer line, press OK
Set FOOTER #4 Enter alpha-numeric for first receipt footer line, press OK
Set GST #
Set PST # if required
Press Menu to access the ADMIN MENU
Press 3 for SET-UP
Press 1 for OPTIONS
Enter Admin Password
NOTE: Debit SURCHARGE Fee is configured by CT-Payment at the time of merchant set-up
Set LANGUAGE
Set APPLICATION MODE (Retail/Restaurant/Driver) using up/down scroll buttons, press OK
Set TERMINAL TYPE to Debit only or both Debit and Credit using up/down scroll buttons, press OK
Set TIP OPTION to ON/OFF using up/down scroll buttons, press OK
IMPORTANT: If Tip is YES, set all of the 3 TIP PRESET functions to 0-0-0 for the PAX S80 model
Set CASH BACK OPTION (Debit Only) to ON/OFF using up/down scroll buttons, press OK
If Cash Back Option is set to YES you can predefine cashback amounts. Default setting is 0-0-0
Set PRESET 1 Cashback amount, press OK
Set PRESET 2 Cashback amount, press OK
Set PRESET 3 Cashback amount, press OK
Set Cash Back Signature Line to ON/OFF using up/down scroll buttons, press OK
Set ENTER LAST 4 DIGITS to activate validation of the last 4 digits of a credit card for swiped transactions
for fraud protection.
Set to ON/OFF using up/down scroll buttons, press OK
Set INVOICE NUMBER to OFF or Manual if tracking invoice numbers with transaction IDs, press OK
Set TERMINAL BACKLIGHT from 0 (dimmest) to 99 (brightest), press OK
Set TERMINAL BUZZER to ON/OFF using up/down scroll buttons, press OK
TERMINAL FUNCTIONS/OPTIONS SET-UP
Set-Up Guide
PAX S80
4

PAX S80 Specifications

General

Processor	32-bit ARM11
Printer	Thermal printer, 18 lines per second
Security	PCI PTS 3.x approved
Connectivity	Ethernet
Card Readers	Magnetic Stripe
Memory	128MB Flash, 64MB SDRAM
Keypad	10 numeric keys, 8 function keys
