WELCOME TO EFFICIENT YEAR-ROUND COMFORT
Congratulations on your excellent choice and sound investment in year-round home comfort!
Your new heat pump represents both the latest in engineering development and the culmination of many years of experience from
one of the most reputable manufacturers of comfort systems.
Your new unit is among the most energy-efficient and reliable heat pump products available today. To assure its dependability, spend
just a few minutes with this booklet now. Learn about the operation of your heat pump, and the small amount of maintenance it takes
to keep it operating at its peak efficiency.
With minimal care, your new heat pump will provide you and your family with year-round home comfort—both now and for years
to come.
Safety Considerations
Recognize safety information. This is the safety-alert symbol .When you see this symbol on the unit and in instructions or
manuals, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and CAUTION. These words are used with the safety-alert symbol. DANGER
identifies the most serious hazards which
will
result in severe personal injury or death. WARNING signifies hazards which
could
result in personal injury or death. CAUTION is used to identify unsafe practices which
would
result in minor personal injury or
product and property damage.
YOUR COMFORT SYSTEM
Identifying Your System
Take the time to familiarize yourself with the type of system you have. This knowledge will be of use in understanding the basic
operation of your new heat pump.
The split-system type has an indoor and an outdoor unit, each of which contains a coil. These units are interconnected by refriger-
ant tubes. (See Fig. 1.)
Each unit has a rating plate affixed to it which provides necessary information for specific identification of a unit. You should
familiarize yourself with the product, model, and serial numbers listed on each rating plate.
WARNING: Improper installation, adjustment, alteration, service, maintenance or use can cause explosion,
fire, electrical shock, or other conditions which may cause personal injury or property damage. Consult a
qualified installer, service agency, or your distributor or branch for information or assistance. The qualified
installer or agency must use factory-authorized kits or accessories when modifying this product.
WARNING: To prevent personal injury, death, or property damage read and follow all instructions and warn-
ings, including labels shipped with or attached to unit before operating your new heat pump.
!
!
!
Fig. 1—Typical Split-System Installation
