AppendixB:BluKeyProFirmwareUpgrade
PayRangemayreleasefirmwareupdateswithnewfunctionalityandimprovements.
BKProfirmwareisupgradedautomatically,inthebackground.ContactPayRangesupportfor
additionalinformationonfirmwareupgrades.

AppendixC:SplicingWires
Onsomemachinespowerhastobetakenfrommachine’swiringharnessorcreditwireshaveto
besplicedtocoinswitchwiringharness.Usethefollowingproceduretosplicewires.
1. Splicingharnesswiresdirectlytomachinewires(dothisprocedureforboth
wires)
Insertoneofthemachinewires
leadingintothecontrolboardinto
thepassthroughofthesplice
Note:Photoshowssplicewithmetal
bracepulledoutforclarity.
Donotremovemetalbrace,butmake
sureitispulledoutenoughsothewire
canbefullyinserted.
Closethe1
st
partofthetab
Note:Photoshowssplicewithmetal
bracepulledoutforclarity.
