PayRange BluKey Pro Series - Battery Connector Pinout; Recommended Mating Parts; Document History

PayRange|BluKeyPro|UserManual
Page22|23
3 IN1 Auxiliaryinput 4 AC2 Powersupplyoutput
5 AC1 Powersupplyoutput 6 RXD SerialRXDatainput
7 GND Commonforallsignals 8 5V_IN 5VDCInput
9 OUT1 Auxiliaryoutput 10 OUT2 Auxiliaryoutput
Notes:
 DirectionofinputandoutputisgivenfromBKPro’sperspective.
 GNDiscommonfor5V_IN,DC_OUTandallinputsandoutputs.
 PowersupplyoutputispassedfromMACHINEconnectorAC1/AC2pins,canbeACorDC.
 DC_OUTderivedbyrectifyingandfilteringinputvoltageprovidedtoMACHINEconnector
AC1/AC2orAC1/GNDinputvoltage.DC_OUTvoltagedependsonactualinputvoltageandtotal
load(40Vfor24VACinput).
 BKProrequires5Vsupplyvoltage(upto64mAload)providedbycardreadertodriveoutput
signalsandreferenceinputsignals.
Attention:DonotconnectCARDconnectorAC1/AC2todevicesthathaveonlyhalf‐waverectifier(oneof
AC1/AC2isconnectedtoGND,andanotherisconnectedtosinglediode).DoingsowilldamageBKPro
andcardreaderdevice.ConnectGND/DC_OUTtothecardreaderpowerinput!
BatteryConnectorPinout
BKProBatteryconnectorisJSTSM02B‐SURS‐TF(2‐pin).ItispresentonlyonRTC‐enablemodels,to
connectbackupbatteryfortheinternalreal‐time‐clock.
Pin Name Type Pin Name Type
1 3V_IN (+)3Vfrombattery 2 GND (‐)Common
Notes:
 RecommendedCR1632.Onlylithium‐based3Vwatchcoincellbatteriesaresupported(e.g.
CR2016,CR2032).
RecommendedMatingParts
MACHINEConnector:JSTPUDP‐12V‐Sfor12‐pinmodels,JSTPUDP‐18V‐Sfor18‐pinmodels.
CARDConnector:JSTPUDP‐10V‐S.
BatteryConnector:JST02SUR‐32S.
DocumentHistory
Issue Date Reason
0.1 16Nov2018 InitialDraft
0.2 3Apr2019 Regulatoryapprovals,electricalcharacteristics,models.
1.0 22Apr2019 CombineReferenceGuideandDataSheetintoUserManual,addFrenchregulatorystatement.
