PB EC Series - Repair Parts

28
REPAIR PARTS
8. REPAIR PARTS
Repair parts are available from your local PB Heat, LLC distributor or from Parts To
Your Door at 1 (610) 916-5380 (www.partstoyourdoor.com).
Note: Remember to include the boiler model number and serial number when ordering parts.
Table 8.1
Part numbers may be subject to change without notice.
Continued on P. 30
Description
Quantity
Required
Stock
Code
1
Block Assembly – EC-e-03 – 90662
Block Assembly – EC-e-04 – 90663
Block Assembly – EC(-e)-05 – 90657
Block Assembly – EC-06 – 90661
Block Assembly – ECT-e-03 – 90664
Block Assembly – ECT-e-04 – 90665
Block Assembly – ECT(-e)-05 – 90658
Block Assembly – ECT-06 – 90660
2 Target Wall – 50768
3
Base Liner, 1/2” x 14” x 6” (03) – 50857
Base Liner, 1/2” x 14” x 10-1/2” (04) – 50858
Base Liner, 1/2” x 14” x 18-3/4” (05/06) – 50846
– Combustion Chamber Insulation Kit 1 50661
4
Burner Mounting Plate Assembly for
Standard Door
1 93530
5 Stud, 5/16-18 x 1” Lg. (Burner to Plate) 4 51748
– Burner Mounting Plate Insulation 1 50765
– Insulation Hardware for Burner Mtg. Plate 1 95016
– Burner Mounting Plate Rope, 3/8” MD 6 ft. 55521
6 Observation Door Round Cover Plate 1 51677
7
Machine Screw, 5/16-18 x 3/4”Lg.
(To Mount Observation Door)
1 99802
8
Machine Screw, 3/8-16 x 1/2” SS
(Observation Port)
1 7511
9 Stud, 5/16-18 x 2-1/4” Lg. (Plate to Block) 3 51747
10 Burner Mounting Plate Internal Hinge 1 3920
11
Bolt, Hex Hd., 5/16-18 x 5/8” Lg.
(Hinge to Block)
2 91588
12
Flue Baffle - EC(T)-e-03 2
51613
Flue Baffle - EC(T)-e-04 3
Flue Baffle - EC(T)-e-05
(For use on Low and Middle rates only)
4
13
Flue Collector & Side Clean Out Assy.
w/ Hardware & Rope/Insulation
EC(T)-e-03, EC-5000
– 99536
Flue Collector & Side Clean Out Assy.
w/ Hardware & Rope/Insulation
EC(T)-e-04, EC-5000-1
– 99537
Flue Collector & Side Clean Out Assy.
w/ Hardware & Rope/Insulation
EC(T)(-e)-05, EC-5000-2
– 99538
Flue Collector & Side Clean Out Assy.
w/ Hardware & Rope/Insulation
EC(T)-06, EC-5000-3
– 99539
Description
Quantity
Required
Stock
Code
14 Flue Collector Rope Seal, 1/2” 7 ft. 51211
15 Stud, 1/4-20 x 1-3/4” Lg. 2 51751
16 Round Cover Plate Gasket 1 51800
17 Round Cover Plate w/ Gasket & Screws 1 99812
18
Tankless Coil – EC WPCT – X-1020-C
w/ Gasket & Screws
1 90534
19 Cap Screw, Hex Hd., 3/8-16 x 3/4” Lg. 6 99788
20 Rectangular Gasket (ECT(-e) Models) 1 90547
21 Rect. Cover Plate w/ Gasket & Screws 1 90140
22
Tankless Coil ECT(-e) SPT – X-1082-C
w/ Gasket & Screws
1 90546
23 Cap Screw, Hex Hd., 3/8-16 x 3/4” Lg. 8 99788
24
Side Clean Out Plate Kit, X-1087 (03) 1 50721
Side Clean Out Plate Kit, X-1087-1 (04) 1 50722
Side Clean Out Plate Kit, X-1087 (05) 2 50721
Side Clean Out Plate Kits, X-1087 &
X-1087-1 (06)
1 each
50721
50722
25
Insulation Board Only for Side Clean
Out Plates
1 per flue 50800
26 Carriage Bolt, 5/16-18 x 1-3/4” Lg. 2 per flue 93997
27
Machine Screw, Truss Hd.,
1/4-20 x 3/8” Lg. (Jacket to Block)
2 91590
28 Screw, #10 x 1/2” Lg., SMS 18 99992
*** JACKETS SOLD ONLY AS ASSEMBLY ***
– EC(T)-e-03 – 90278
– EC(T)-e-04 – 90279
– EC(T)(-e)-05 – 90280
– EC(T)-06 – 90281
