Install the Processor
Jumper JP3: Enable/Disable Onboard LAN
Use this 3-pin jumper to enable or disable the onboard network
adapter.
Function Jumper Setting
Enable Onboard LAN Short Pins 1-2
Disable Onboard LAN Short Pins 2-3
Jumper JP9: Enable/Disable Onboard Fax/modem
Use this 3-pin jumper to enable or disable the onboard fax/modem
card. If the audio jumper JP4 is disabled, the fax/modem is also
disabled, no matter the setting of JP9.
Function Jumper Setting
Disable Onboard Modem Short Pins 1-2
Enable Onboard Modem Short Pins 2-3
JP7: Select Slot-1 or Socket-370 Processor
Use this 3-pin jumper to prepare the mainboard to use either a Slot-
1 processor or a Socket-370 processor.
Function Jumper Setting
Slot-1 Processor Short Pins 1-2
Socket-370 Processor Short Pins 2-3
