6
3-2 Electrical Specifications
Unless otherwise stated, the following specifications hold under
the following conditions :
• The meter is located in the far-field of a source, the sensor head is
pointed towards the source.
• Ambient temperature : +23℃±3℃
• Relative air humidity : 25% to 75%
Sensor type : Electrical field (E)
Frequency range : 10MHz to 8GHz
Specified measurement range :
• CW signal (f > 50MHz) : 20mV/m to 108.0V/m ,
53µA/m to 286.4mA/m ,
1µW/m
2
to 30.93W/m
2
,
0µW/cm
2
to 3.093mW/cm
2
Dynamic range : Typically 75dB
Absolute error at 1 V/m and 50 MHz : ±1.0dB
Frequency response :
• Sensor taking into account the typical CAL factor :
±1.0dB (50MHz to 1.9GHz)
±2.4dB (1.9GHz to 8GHz)
• Isotropy deviation : Typically ±1.0dB (f>50MHz)
• Overload limit : 10.61mW/cm
2
(200V/m)
• Thermal response (0 to 50℃) : ±0.5dB
