PCE Instruments PCE-GA 12 User Manual

© PCE Instruments
3
4 Technical specifications
Measurement range
Low concentration: 0 ... 1000 ppm,
High concentration: 0 ... 10000 ppm
(methane only)
Audible alarm
Volume: 85 dB
Sensitivity
<10 ppm (methane)
Measuring interval
<2 seconds
Display
Flammable gas readings displayed on the LC display, bar
graphs
Calibration
Automatic
Warm-up time
40 seconds
Battery
Polymer Li-Ion battery 18500 3.7 V 1400 mAh
Mains adaptor
Primary side: 100 ... 240 V, 50/60 Hz, 0.2 A
Secondary side: 5 V, 1 A
Auto Power Off
Turns off automatically when battery is low or after 10 minutes
of inactivity
Sensor shelf life
approx. 5 years (sensor is exchangeable)
Probe
Semi-rigid, approx. 500 mm
Weight
Approx. 430 g
5 Delivery contents
− 1 x gas leak detector PCE-GA 12
− 1 x charger
− 1 x user manual

PCE Instruments PCE-GA 12 Specifications

General

Brand	PCE Instruments
Model	PCE-GA 12
Category	Security Sensors
Language	English
