PCM 2007 6.0L MPI - ZR6 390 User Manual

58
L510010-07A
ENGINE SPECIFICATIONS - 12
Figure 12-1 V-8 Firing Orders
1
3
5
7
2
4
6
8
1
3
5
7
2
4
6
8
5.0 / 5.7 Liter
LH ROTATION
FRONT
6.0 Liter
LH ROTATION
FRONT
NO
DISTRIBUTOR
FIRING ORDER:
1-8-4-3-6-5-7-2
FIRING ORDER:
1-8-7-2-6-5-4-3
FLYWHEEL END OF ENGINE
ALL V-8 MODELS
1
7
c
6
4
2
8
3
5
Rotation
TUNE-UP SPECIFICATIONS
Model
MP 5.0L (275 HP)
MP 5.7L (343 HP) MP 6.0L (390 HP)
Spark Plug Type R030010
R030011
Spark Plug Gap
0.060 in. 0.060 in.
(1.52 mm) (1.52 mm)
Ignition Timing
Fixed, Fixed,
Not Adjustable Not Adjustable
Firing Order
1-8-4-3-6-5-7-2
1-8-7-2-6-5-4-3
(LH Rotation) (LH Rotation)
CAM Retard 0-4 degrees
Not Adjustable
