PCM HO303 MPI User Manual

66
L510010-11
WATER FLOW DIAGRAMS - 15
2
From Sea
Water Pickup
Note: This diagram is for illustration purposes only. The actual routing and/or shape of the hoses may vary slightly depending on installation.
P
L
E
A
S
U
R
E
C
R
A
F
T
E
N
G
IN
EG
R
O
U
P
P
OWERPLU
S
R
A
T
I
O
1.48
M
A
D
E
INU
S
A
Raw Water
Drain Plug
1/2”
Square
PCM V-Drive
1
1
1
2 3
3
3
4
4
5
5
5
Drain Locations - Engine Block Drains - Remove Knock Sensors - Engine Circulating Water Pump Pipe - Remove Drain Plug - Exhaust Manifolds - Remove Drain Plugs - Transmission Cooler - Remove Inlet Hose - VDrive - Remove Drain Plug
Figure 15-2 Vee Drive Raw-Water Cooling System HO303 / EX343
