67
L510010-11
Figure 15-3 Direct Drive Half-System HO303 / EX343
From Sea
Water Pickup
Note: This diagram is for illustration purposes only. The actual
routing and/or shape of the hoses may vary slightly depending
on installation.
1
1
2
2
2
3
3
Drain Locations
- Heat Exchanger - Remove Drain Plug
- Exhaust Manifolds - Remove Drain Plugs
- Transmission Cooler - Remove Inlet Hose
WATER FLOW DIAGRAMS - 15
To Next Page
