PCM HO303 MPI User Manual

70
L510010-11
Figure 15-6 Vee Drive CES HO303 / EX343
From Sea
Water Pickup
Note: This diagram is for illustration purposes only. The actual routing and/or shape of the hoses may vary slightly depending on installation.
P
L
E
AS
U
RE
C
R
AF
T
E
NGIN
EGROU
P
POWER
PLU
S
R
A
T
I
O
1
.
4
8
M
ADEINU
S
A
Raw Water
Drain Plug
1/2”
Square
PCM V-Drive
1
1
1
2
2
3
3
3
4
4
5
5
5
6
6
6
Drain Locations - Engine Block Drains - Remove Knock Sensors - Engine Circulating Water Pump Pipe - Remove Drain Plug - Exhaust Manifolds - Remove Drain Plugs - Transmission Cooler - Remove Inlet Hose - Exhaust System Corners - Remove Drain Plugs - VDrive - Remove Drain Plug
WATER FLOW DIAGRAMS - 15
