Earthing
Where the item to be tested is not earthed to ground, a
ground spike must be attached.
The unit should always be switched off before removing and
repositioning the earth lead. After the earth is repositioned, the
probe should always be flashed on the substrate to prove a
good contact has been made.
Leads
Carbon cored 22kΩ High Voltage leads must be used.
Use of copper cored leads will void warranty.
3.0 SPECIFICATIONS
Weight: 2.2kg
Display: LCD 3¾ digits with battery indicator
Voltage 0 to: DC15: 15kv DC30: 30kv
Resolution: 10v 10v
Short circuit: Test current less than 0.5mA
Power supply: 3Ah Slide-off
Recharge Time: 400mA for 10hrs.
Battery Test: When Porosity (Holiday) Detector is switched on,
the result is displayed on the LCD.
Dimensions: 260 x 160 x 70mm
Alarms: Audible – with sensitivity adjustment.
Visual – front panel light.
Neon in probe – 360° visibility
Probe lead: 2m carbon-cored high-voltage silicon-rubber.
Earth lead: 7m silicon-rubber with a clamp fitted to one end.
Probes: 250mm Flat Brass Wire brush, trim length of 50mm
Carry Case: 150 x 370 x 440mm
Optional coils & brushes available: See accessories pages
STORAGE:
The Detector should be stored in a dry place. Leads should
not be wound tightly. Battery should be fully charged.
