40
4.2.5 RS232 Communication
1. Data Request Configuration
5 Byte 1 Byte 3 Byte 1 Byte 4~6 Byte 1 Byte
ID BL C1 BL C2 LF
3. Data Indication
5 Byte 1 Byte 3 Byte 1 Byte 4 Byte 1 Byte
ID BL C1 BL C2 CR
CR[001] GET INFO
[001] ID NO : [001]
Model Name : Jain- 2 KD
Serial_No. : 2020G01-0001
Sensor Range : -2.0 ~ 2.0 K{ETX}
< Response Example >
2. Data Response Configuration
1 Byte 5 Byte 1 Byte 1 Byte 1 Byte
STX ID D1 CR LF EOT
ID will shows as [xxx], D1 has up to 25 Bytes of output data.
<RS232 Communication Set>
Baud Rate : 19200 Data Bit Length : 8 bit
Stop Bit : 1 bit Parity : None
Data flow control : N/A Data Code : ASCII code
<Description>
BL : Blank C1 : Command1
LF : Line Feed
CR : Carriage Return STX : Start of text
D1 : Data EOT : End of text
C2 : Command2
