Peak Scientific NM20ZA - Unpacking and Installation

NM20ZA Service Manual Rev 14
NM20ZA
Service Manual – Revision 13
4 NM20ZA – Technical Specification
Generator Environment
Minimum Operating Ambient Temperature 5
o
C (41
o
F)
Maximum Operating Ambient Temperature 30
o
C (86
o
F)
Maximum Relative Humidity 70%
Outlet Gas
Maximum Gas Outlet Pressure Curtain 60 psig
Maximum Gas Outlet Pressure Source 100 psig
Maximum Gas Outlet Pressure Exhaust 60 psig
Maximum Gas Outlet Flow (Zero Grade Air) 30 Litres/min (ATP)
Maximum Gas Outlet Flow (High Purity Nitrogen) 5 Litres/min (ATP)
Start up time for Purity 60 minutes
Air filtration to 0.01um
Electrical Requirements
@230V±10% ac (50/60Hz) 5.0 Amps
Compressor Circuit Breaker 8.0 Amps
Control Circuit Breaker 2.0 Amps
Electrical Connection Single Phase Power Cord
General
Dimensions W x D x H cm
(inches)
60 x 67 x 94
(24 x 27 x 37)
Weight Kg
(lbs)
112.5
(248)
Shipping Weight Kg
(lbs)
169
(372)
7
