Peak Scientific NM20ZA - Installation Details

NM20ZA Service Manual Rev 14
NM20ZA
Service Manual – Revision 13
5 Connection to the Instrument
1 off 1/8" x 1/4" Compression Fitting (02-1009)
with 1/4" Tubing (00-1266)
Curtain Gas Outlet.
Source Gas Outlet.
Exhaust Gas Outlet.
(04-1038-EU)
(04-1030-UK)
230Vac
(04-1029-US)
Power Cord
Rear View.
3 off 1/4" x 1/4" Compression Fitting (02-4421)
with 1/4" Tubing (00-1266)
*
#
*
#
2- off 1/4" x 1/8" Comp. Fitting (02-1000)
2 off 1/4" x 1/4" Comp. Fitting (02-4421)
3 off 1/4" x 1/4" Comp. Fitting (02-4421)
1 off 1/4" Double Nipple (02-4399)
2- off 1/4" x 1/8" Swagelok (02-1000)
2 off 1/4" Tee (02-4307)
APi 4000 / Q Star
with 1/8" Tubing (00-1262)
1 off 1/4" Tee (02-4307)
APi 3000
*
#
8
