15
K. Install hydraulic power unit and oil hose assy. (See Fig. 27).
Tighten all the hydraulic fittings, and fix the oil hose by retainer.
Note: In consideration of Power Unit’s durability and keep the equipment running
in the perfect condition, please use Hydraulic Oil 46#
Fig. 27
Locking the nut using 19#
ratchet spanner
76
75
68
Fix the oil hose by
retainer.
5
