IX. PARTS LIST FOR MODEL 209 and 209X
A. Parts For Model 209 (See Fig. 39, Fig. 6)
Item
Part#
Description
Qty.
Note
1
205001B
Powerside column
1
2
209011
Plastic pulley
1
3
209010
Snap ring
2
4
209008
Safety cover
2
5
209009
Cup head bolt
6
6
206006
Washer
2
7
206023A
Hex nut
2
201
209002
Manual power unit
1
9
209006
Safety pin
2
10
209007
Safety spring
2
11
203002
Powerside safety lock
1
12
209012
Hair pin
8
13
203015
Safety block (Main)
1
14
209003
Hex bolt
4
15
209004
Rubber ring
4
16
209005
Self locking nut
8
17
205002
Floor cover
1
18
209052B
Stackable Adapter (2.5”)
4
19
209051B
Stackable Adapter (1.5”)
4
20
201039B
Lifting Arm-Rear
2
20A
201050
Outer Arm-Rear
2
20B
201051A
Inner Arm-Rear
2
21
201046A
Rubber Pad Assy.
4
21A
420138
Socket bolt
4
21B
209134
Rubber Pad
4
21C
680030C
Rubber Pad Frame
4
22
209057
Small pulley
4
23
209056
Self locking nut
2
24
201043A
Lifting Arm-Front
2
24A
201047
Outer Arm-Front
2
24B
201048
Middle Arm-Front
2
24C
201049A
Inner Arm-Front
2
25
201010A
Chain connector
4
26
201009A
Chain
2
27
201008A
Hydraulic cylinder
2
28
201007A
Pin for chain pulley
2
29
203004A
Bronze bush for chain pulley
4
30
201006
Chain pulley
2
31
201005
Split pin
2
32
201004
Chain pulley assy.
2
33
205003
Powerside Carriage
1
34
206044
Slider
16
35
209016
Carriage plastic cover
2
36
206045
Protective rubber
2
