1
I. PRODUCT FEATURES AND SPECIFICATIONS
FLOORPLATE CHAIN-DRIVE MODEL FEATURES
Model 209 (See Fig. 1)
· Compact design
· Dual hydraulic cylinders, designed and made on ANSI standards, utilizing NOK oil
seal in cylinder
· Self- lubricating UHMW Polyethylene sliders and bronze bush
· Single-point safety release, and dual safety design
· Supersymmetric arms design with 3-stages front arms and 2-stages rear arms
. Stackable rubber pad with 1.5” and 2.5” extension adaptors
MODEL 209 SPECIFICATIONS
Model
Style
Lifting
Capacity
Lifting
Time
Lifting Height
Overall
Height
Overall
Width
Width
Between
Columns
Minimum
Pad
Height
Gross
Weight
Motor
209
Floorplate
Chain-drived
4.0T
9,000lbs
45S
1815-1917mm
71 1/2” – 75 1/2”
2742mm
108”
3350mm
132”
2780mm
109 1/2”
90mm
3 1/2”
610Kg
1,345 lbs
2.0/3.0
HP
Fig. 1
