Peak 212 - Safety Device Installation

10
2. Using the prescribed rotary hammer drill, and drill all the anchor holes and install the
anchor bolts. Then tighten the anchor bolts (See Fig. 16).
Note: Torque of Anchors is 150N.m. Minimum embedment of anchors is 110mm.
G. Install safety device (See Fig. 17&18).
Power side safety device
Fig. 17
Fig. 16
58
57
59
60
52
6
56
55
61
64
63
65
66
67
69
62
68
Offside safety device
Fig. 18
110mm
