Atlas LCR45 User Guide January 2019 – Rev 4
Page 4
Important Notices
WARNING:
This instrument must NEVER be connected to powered
equipment/components or equipment/components with
any stored energy (e.g. charged capacitors).
Failure to comply with this warning may result in
personal injury, damage to the equipment under test,
damage to the LCR45 and invalidation of the
manufacturer's warranty. Non-destructive overload
situations are stored in the non-volatile memory within
the LCR45 to help Peak with repair diagnostics.
“Analysis of discrete, unconnected components is
recommended.”
The LCR45 is designed to provide accurate and reliable
information for the majority of supported component types
(inductors, capacitors and resistors) as described in the
technical specifications. Testing of other component types or
component networks may give erroneous and misleading
results.
