4.4.1 With LDF (LIN Description File)
Note: An LDF must be provided by the system manufacturer of the LIN
bus or created by the customer.
Application examples with an LDF:
■
Master with scheduler: The Publisher data is edited in the Transmit window
and assigned to the Scheduler with the |Space bar|.
■
Slave (Listen Only): Selecting "All - Listen Only" will receive the data as a silent
listener.
■
Slave (LIN node simulation): The publisher data of the slave are changed in
the Publish window. With the |Space bar| the data is sent to the hardware and
thus made available on the LIN bus.
■
Master with LIN diagnostic frames: Diagnostic frames 3C/3D are processed via
a script to be created by the customer for the LDF used. Examples can be found
in the Help.
4.4.2 Manually
Manual sending is done according to the connected hardware as master or slave.
Frames are configured beforehand for this. For periodic sending, a scheduler can
also be created.
Note: In the following example, a frame is sent manually from a
master as publisher without a scheduler. For automated sending,
further expertise in configuring LIN frames and at least one additional
LIN node are required.
