4. Specifications
4.1. max. Input values
Function
max. Input
AC Power
750 kW
ACA
1000 A
VAC
750 V
4.2. AC Voltage (True RMS)
Rage
Re-
solution
Accuracy
Input
Impe-
dance
Frequency
Range
100 V
0.1V
± (1.2 % + 5)
10 M
50 Hz ~ 200 Hz
400 V
750 V
4.3. Frequency
Range
Resolution
Accuracy
50 Hz ~ 200 Hz
1 Hz
± (0.5 % + 5)
4.4.AC Current (True RMS)
Range
Resolution
Accuracy
Frequency Range
40 A
0.1 A
± (2 % + 5)
50 Hz ~ 60 Hz
100 A
400 A
1000 A
1 A
-35-
