6.4. Apparent Power (main display) + Reactive Power
(secondary display) Measurement
* Please use the rotary switch and select “kVA” and proceed
as under 6.2.
6.5. Reactive Power (main display) + Apparent Power
(secondary display) Measurement
* Please use the rotary switch and select “kVAR” and proceed
as under 6.2.
6.6. Power Factor (main display) + Phase Angle
(secondary display) Measurement
* Please use the rotary switch and select „cos “ and proceed
as under 6.2.
6.7. AC Voltage (main display) + Frequency (secondary
display) Measurement
-50-
Red
Blue
Yellow
