Peavey Bandit 112 Service Manual

PARTS LIST
- 14 -
R63 RCF 1/4W 10K 5% AT 4705-103J-2
R64 RCF 1/4W 1K 5% AT 4705-102J-2
R65 RCF 1/4W 100K 5% AT 4705-104J-2
R66 RCF 1/4W 15K 5% AT 4705-153J-2
R67 RWR 5W 5.6 OHM 5% AL 474B-5R6J-1
R69 RCF 1/4W 4.7K 5% AT 4705-472J-2
R71, R72 RWR 5W 0.33 OHM 5% AL 474B-R33J-1
R73 RCF 1/4W 1K 5% AT 4705-102J-2
R74 RCF 1/4W 2.2K 5% AT 4705-222J-2
R75 RCF 1/4W 10K 5% AT 4705-103J-2
R76 RCF 1/4W 47K 5% AT 4705-473J-2
R77, R87 RWR 5W 150 OHM 5% RL 474B-151J-5
R78-R79 RMF 1/4W 47R 5% AT FP 4715-470J-2-P
R80 RCF 1/4W 2.7K 5% AT 4705-272J-2
R81-R83 RCF 1/4W 10K 5% AT 4705-103J-2
R84 RCF 1/4W 220K 5% AT 4705-224J-2
R85 RCF 1/4W 10R 5% AT 4705-100J-2
R86 RCF 1/4W 47K 5% AT 4705-473J-2
R88 RCF 1/4W 470R 5% AT 4705-471J-2
R89 RCF 1/4W 4.7K 5% AT 4705-472J-2
R90 RCF 1/4W 4.7K 5% AT 4705-472J-2
R91 RMF 2W 6.8K 5% ATS METAL 4719-682J-C-X
R92 RCF 1/4W 470R 5% AT 4705-471J-2
R93 RCF 1/4W 470K 5% AT 4705-474J-2
SWITCHES
S1 SWITCH PBS-22H01(L) F18 5200-9175-0
S2 SW 4P2T-LS-1842022-A 5200-3620-0
TB1 THERMAL SW US-602SXRFQL 5200-3708-0
ICs
U1-U3 IC UPC4560C-DUAL OP. AMP 3130-2010-0
U6 IC DG211CJ ANALOG SWITCH 3131-6770-0
VOLUMES
VR1 VR XVB12102PHJN15FS-15C 4750-5495-0
VR2 VR XVB12102PHJN15FS-15A 4750-5485-0
PRE-AMP ASSEMBLY
CAPACITORS
C1 CM 50V 3300pF 10% RL 6x1 153F-332K-5-KW
C2 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C3 CM 100V 0.22µF 10% RL 153H-224K-5-VYA
C4 CM 50V 3900pF 5% 153F-392J-5-KW
C5 CM 50V 0.047µF 5% RL 153F-473J-5-NR
C6 CC 50V 270pF 10% AT 3.5x 150F-271K-2-FC
C7 CM 100V 0.1µF 10% RB 153H-104K-9-NL
C8 CM 50V 0.047µF 5% RL 153F-473J-5-NR
C9 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C10 CM 50V 6800pF 5% RL 5.5x 153F-682J-5-JQ
Ref. No. Description Mfr’s Part No.

Peavey Bandit 112 Specifications

General

Power Output	80 Watts RMS
Channels	2 (Clean and Lead)
Effects	Reverb
Effects Loop	Yes
Speaker	12-inch
Outputs	1 x Headphone
Footswitch	Optional (for channel switching)
EQ	3-band EQ per channel
