Peavey Bandit 112 Service Manual

PARTS LIST
- 15 -
C11 CC 50V 270pF 10% AT 3.5x 150F-271K-2-FC
C12 CC 50V 0.022µF 10% AT 150F-223K-2-FD
C13 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C14 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C15 CC 50V 0.022µF 10% AT 150F-223K-2-FD
C16 CM 50V 0.012µF 5% RL 153F-123J-5-KMF
C17 CM 100V 0.1µF 10% RB 153H-104K-9-NL
C18 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C19 CC 50V 0.047µF 10% AT 150F-473K-2-FD
C20 CC 50V 1000pF 10% AT 3.5 150F-102K-2-FC
C21 CC 50V 270pF 10% AT 3.5x 150F-271K-2-FC
C22 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C23 CM 50V 1500PF 5% RL 153F-152J-5-JM
C24, C25 CC 50V 0.047µF 10% AT 150F-473K-2-FD
C26 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C27 CC 50V 1000pF 10% AT 3.5 150F-102K-2-FC
C28 CC 50V 470pF 10% AT 3.5x 150F-471K-2-FC
C29 CM 100V 0.22µF 10% RL 153H-224K-5-VYA
C30 CC 50V 470pF 10% AT 3.5x 150F-471K-2-FC
C31 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C32 CC 50V 0.015µF 10% AT 150F-153K-2-FD
C33 CC 50V 0.0068µF 10% AT 150F-682K-2-FD
C34 CC 50V 820pF 10% AT 3.5x 150F-821K-2-FC
C35 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C36 CC 50V 0.022µF 10% AT 150F-223K-2-FD
C37 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C38, C39 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C41 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C42 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C43 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C44 CC 50V 0.022µF 10% AT 150F-223K-2-FD
C45 CC 50V 27pF 5% RL 4x4 150F-270J-5-GG
C48 CC 50V 100pF 10% AT 3.5x 150F-101K-2-FC
C49 CE 50V 2.2µF 20% RL 5x11 157F-225M-5-IU
C50 CC 50V 0.015µF 10% AT 150F-153K-2-FD
C51, C5 CC 50V 100pF 10% AT 3.5x 150F-101K-2-FC
C53 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C54 CM 63V 0.47µF 5% RL 7.5x 153I-474J-5-NO
C55 CC 50V 0.047µF 10% AT 150F-473K-2-FD
C56-C58 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C59 CE 50V 220µF 20% RL 157F-227M-5-S5
C60-C63 CC 50V 0.1µF 10% AT 150F-104K-2-FC
C64 CE 50V 22µF 20% RL 5X11 157F-226M-5-IU
C65 CE 50V 2.2µF 20% RL 5x11 157F-225M-5-IU
C66 CC 50V 100pF 10% AT 3.5x 150F-101K-2-FC
C67 CC 50V 0.01µF 10% AT 3.5 150F-103K-2-FC
C68 CC 50V 470pF 10% AT 3.5x 150F-471K-2-FC
DIODES
CR1-CR4, CR6-CR13 DIODE 1N4148 ATS 4804-1480-C
Ref. No. Description Mfr’s Part No.

Peavey Bandit 112 Specifications

General

Power Output	80 Watts RMS
Channels	2 (Clean and Lead)
Effects	Reverb
Effects Loop	Yes
Speaker	12-inch
Outputs	1 x Headphone
Footswitch	Optional (for channel switching)
EQ	3-band EQ per channel
