Peavey Bandit 112 Service Manual

PARTS LIST
- 16 -
CR19, CR20 DIODE 1N4148 ATS 4804-1480-C
SOCKETS
J1, J2 JACK SOCKET (MONO) 2113-1343-0
P7 JM2422-4R WAFER 2101-9920-0
TRANSISTORS
Q1-Q10 TR 2SC1740SLN 'R' HFE 4860-5370-5
Q11 TR 2SA933ASLN 'R' HFE 4860-5380-5
Q12-Q14 FET J-174 P-CHANNEL IDSS 490J-1740-5
RESISTORS
R1 RMF 1/4W 133K 1% AT 4715-1333-2
R2 RCF 1/4W 680K 5% AT 4705-684J-2
R3 RMF 1/4W 37.4K 1% AT 4715-3742-2
R4 RCF 1/4W 2.2M 5% AT 4705-225J-2
R5 RMF 1/4W 105K 1% AT 4715-1053-2
R6 RCF 1/4W 100K 5% AT 4705-104J-2
R7 RCF 1/4W 22K 5% AT 4705-223J-2
R8 RCF 1/4W 4.7K 5% AT 4705-472J-2
R9 RMF 1/4W 25.5K 1% AT 4715-2552-2
R10 RCF 1/4W 470K 5% AT 4705-474J-2
R11 RCF 1/4W 2.2M 5% AT 4705-225J-2
R12 RCF 1/4W 68K 5% AT 4705-683J-2
R13 RMF 1/4W 243K 1% AT 4715-2433-2
R14 RCF 1/4W 100K 5% AT 4705-104J-2
R15 RCF 1/4W 22K 5% AT 4705-223J-2
R16 RCF 1/4W 100K 5% AT 4705-104J-2
R17 RCF 1/4W 3.3K 5% AT 4705-332J-2
R18 RCF 1/4W 39K 5% AT 4705-393J-2
R19 RMF 1/4W 4.53K 1% AT 4715-4531-2
R20 RCF 1/4W 68K 5% AT 4705-683J-2
R21 RCF 1/4W 1.5K 5% AT 4705-152J-2
R22, R23 RCF 1/4W 1M 5% AT 4705-105J-2
R24 RCF 1/4W 47R 5% AT 4705-470J-2
R25 RCF 1/4W 330K 5% AT 4705-334J-2
R26 RMF 1/4W 150K 1% AT 4715-154A-2
R27 RCF 1/4W 2.2M 5% AT 4705-225J-2
R28 RMF 1/4W 68K 1% AT 4715-683A-2
R29 RMF 1/4W 150K 1% AT 4715-154A-2
R30 RCF 1/4W 82K 5% AT 4705-823J-2
R32 RMF 1/4W 243K 1% AT 4715-2433-2
R33 RCF 1/4W 68K 5% AT 4705-683J-2
R34, R35 RCF 1/4W 47K 5% AT 4705-473J-2
R36 RCF 1/4W 1M 5% AT 4705-105J-2
R37, R38 RCF 1/4W 470K 5% AT 4705-474J-2
R39, R40 RCF 1/4W 1M 5% AT 4705-105J-2
R41 RCF 1/4W 220K 5% AT 4705-224J-2
R43 RCF 1/4W 470K 5% AT 4705-474J-2
R44 RCF 1/4W 10K 5% AT 4705-103J-2
Ref. No. Description Mfr’s Part No.

Peavey Bandit 112 Specifications

General

Power Output	80 Watts RMS
Channels	2 (Clean and Lead)
Effects	Reverb
Effects Loop	Yes
Speaker	12-inch
Outputs	1 x Headphone
Footswitch	Optional (for channel switching)
EQ	3-band EQ per channel
