Current Consumption
(Multiply current by 0.5 for 230 V units)
Rated power 15.4 A (4 Ohms) 13.2 A
9.9 A (8 Ohms)
1/3 power 9.9 A (4 Ohms) 8.6 A
6.3 A (8 Ohms)
1/8 power 6.6 A (4 Ohms) 5.8 A
4.2 A (8 Ohms)
Idle 0.4 A 0.7 A
Thermal Emission
1/3 power 3147 BTU/hr (4 Ohms) 2614 BTU/hr
1990 BTU/hr (8 Ohms)
1/8 power 2364 BTU/hr (4 Ohms) 2036 BTU/hr
1500 BTU/hr (8 Ohms)
Controls
Front: 4 channel input signal attenuators‚ AC switch
Rear: 2 x 4 DIP switches for input module assign‚ 2 output mode switches
Indicator LEDs
4 clip‚ 4 signal‚ 1 power
Protection
Over-temperature‚ DC‚ turn on/off transients‚ subsonic‚ incorrect load‚ short-circuit
Connectors
Input: Four 3-position Euro-style detachable terminal blocks‚ two ports for MMA
™
input modules
Output: Two 4-position barrier strips
CCoonnssttrruuccttiioonn
16-gauge steel-reinforced with 12-gauge rack ears
DDiimmeennssiioonnss
Height: 3.50" (8.84 cm); 2 EIA rack spaces
Width‚ front: 19.00" (48.26 cm)
Width‚ rear: 17.00" (43.18 cm)
Overall depth: 17.05" (43.31 cm)
Mounting depth: 16.63" (42.24 cm) behind front rack ears
WWeeiigghhtt
40 lbs. (18.1 kg)
PPoowweerr RReeqquuiirreemmeennttss
120 VAC, 60 Hz
TTeesstt CCoonnddiittiioonnss
120 VAC‚ 60 Hz line input voltage maintained
All channels operating unless otherwise noted
ICS
™
4200 power amplifierSpecifications
