Program
Retention
The
Programax
10
contains
a
special
rechargeable
internal
battery
to
protect
and
maintain
stored
programs
while
the
amplifier
is
not
in
use.
When
the
amplifier
is
in
use
(power
on),
an
internal
circuit
automatically
rechargesthe
battery
During
periods
when
the
amplifier
is
not
in
use.
user-input
programs
will
be
retained
in
memory
for
approximately
three
weeks.
Factory-input
programs
will
be
retained
indefinitely.
If
the
Programax
10
is
turned
off
for
a
prolonged
period
of
time
(several
weeks
or
longer),
all
user-input
programs
may
be
lost
from
memory.
If
this
occurs,
the
amplifier
will
automatically
revert
to
the
original
factory-input
programs.
It
is
recommended,
therefore,
that
any
user-input
programs
be
recorded
in
writing
in
case
the
need
for
reprogramming
arises.
Under
conditions
of
normal
use,
the
internal
battery
should
have
a
life
expectancy
in
excess
of
five
years.
Battery
failure
is
indicated
if
the
Programax
10
refuses
to
retain
user-created
or
user-modified
programs
during
a
power-off/power-on
cycle.
Since
the
battery
is
an
integral
component
of
the
amplifier’s
circuitry,
replacement
of
the
battery
should
be
performed
only
by
an
Authorized
Peavey
Dealer
or
qualified
service
technician.
Program
Detetion/Retum
to
Factory
Preset
Programs
Capability
is
provided
to
simultaneously
delete
all
user-input
programs
from
the
amplifier’s
memory.
When
this
is
done,
the
Programax
10
will
automatically
revert
to
the
ten
original
"factory”
programs.
NOTE:
THIS
PROCEDURE
WILL
CAUSE
DES¬
TRUCTION
OF
ALL
USER-INPUT
INFORMATION.
The
following
procedure
will
clear
user-input
memory:
1.
Turn
the
amplifier
off.
2.
Press
and
hold
BOTH
the
BANK
A/B
key
(M)
and
the
MAN
key
(T).
3.
While
holding
both
keys
in
position,
turn
the
amplifier
on.
W
X
Z
AA
Programax.
ID
ffiGl
r,„
_
n»'Oi
cos'
io
too’
&ait
/
BB
O
pi)
Pi.
'
•'I
-
-
•O'.i’’
«
ii''
REAR
PANEL
FEATURES
Pre-EQ
Patch
In/Out
Jack
(W)
This
stereo-type
jack
allows
access
to
the
Pre-EQ
effects
loop
(Effects
Loop
#1).
This
effects
loop
is
low
level
(0.2V
RMS.
-14
dBV),
and
is
intended
to
drive
effects
devices
and
pedals
primarily
designed
for
instrument-level
signals.
Most
small
battery-
operated
or
passive
devices
fall
into
this
category.
Toconnect
an
effects
device
to
the
Pre-EQ
effects
loop,
a
shielded
stereo
Y-cord
should
be
used.
The
SEND
signal
is
present
at
the
TIP
of
the
jack,
and
the
RETURN
signal
is
present
at
the
RING
of
the
jack.
The
SEND
signal
should
be
routed
to
the
input
of
the
effects
device,
and
the
RETURN
signal
originates
at
the
device’s
output.
Please
note
that
the
Pre-EQ
effects
loop
is
not
active
unless
the
EFX1
indicator
(Q)
is
illuminated
on
the
front
panel.
Post-EQ
Patch
In/Out
Jack
(X)
This
stereo-type
jack
allows
access
to
the
Post-EQ
effects
loop
(Effects
Loop
#2).
The
Post-EQ
effects
loop
is
designed
to
accommodate
line-level
effects
devices
and
provides
a
suitable
signal
(1.0V
RMS.
0
dBV)
to
drive
such
devices.
As
previously
discussed
in
the
Pre-EQ
Patch
section,
a
shielded
stereo
Y-cord
should
be
used
to
connect
an
effects
device.
The
SEND
signal
appears
at
the
TIP
of
the
jack,
and
the
RETURN
signal
is
present
at
the
RING
of
the
jack.
Level
balancing
of
the
Post-EQ
effects
loop
is
accomplished
by
adjusting
the
Post-EQ
Level
Control
(Y).
Please
note
that
the
Post-EQ
effects
loop
is
not
active
unless
the
EFX2
indicator
(R)
is
illuminated
on
the
front
panel
Post-EQ
Level
Control
(Y)
The
Post-EQ
Level
Control
regulates
the
return
level
of
signals
routed
through
the
Post-EQ
Patch
Jack
(X).
Some
effects
devices
may
not
provide
unity
gain
(signal
input
and
output
levels
may
not
be
equal),
and
the
Post-EQ
Level
Control
may
be
used
to
restore
gain
balance.
It
should
be
noted
that
the
Posl-EQ
Level
Control
is
operable
whenever
the
EFX2
effects
loop
is
enabled.
The
control
will,
therefore,
affect
signal
levels
even
if
no
effects
devices
are
connected
to
the
amplifier.
If
no
post-EQ
effects
are
to
be
connected
to
the
amplifier,
it
is
recommended
that
the
control
be
rotated
to
its
full
clockwise
position.
This
setting
will
prevent
the
possibility
of
gain
reduction
if
the
EFX2
effects
loop
is
inadvertently
enabled.
MIDI
In
Socket
(Z)
The
MIDI
In
Socket
is
a
standard
DIN
connector
which
allowsfor
a
MIDI
controller
interface
to
the
Programax
10.
When
such
an
i
nterface
is
establ
ishea,
prog
rams
stored
within
the
amplifier
may
be
recalled
from
any
remote
MIDI
controller,
such
as
the
Peavey
RMC
2000.
The
Programax
10
is
a
MIDI
slave
device
only;
it
is
not
intended
to
control
other
MIDI-compatible
devices.
The
amplifier's
microprocessorcan
receive
information
on
Channel
1
only
and
will
select
any
of
the
ten
stored
programs
in
response
to
commands
MIDI
Preset
Select
1
through
MIDI
Preset
Select
10.
Any
other
codes
will
be
ignored
by
the
internal
microprocessor.
MIDI
Thru
Socket
(AA)
The
auxiliary
MIDI
output
is
provided
to
allow
chaining
of
MIDI-compatible
devices
without
the
use
of
Y-type
cables
or
connectors.
Any
and
all
control
signals
received
at
the
MIDI
In
Socket
(Z)
will
be
routed
unaltered
to
the
MIDI
Thru
Socket.
Line
Cord
(BB)
For
your
safety,
the
Programax
10
incorporates
a
three-wire
AC
(mains)
cable
with
proper
grounding
facilities.
Do
not
remove
the
ground
pin
under
any
circumstances.
If
it
is
necessary
to
use
the
amp
without
proper
grounding
facilities,
a
suitable
grounding
adaptor
should
be
used
Much
less
noise
and
greatly
reduced
shock
hazard
exist
when
the
unit
is
operated
with
properly
grounded
receptacles.
