Gain
Frequency Response
Total Harmonic Distortion
Hum and Noise
Equivalent Input Noise
Mic Input Gain Adjustment Range: 4 dB to 59 dB
Mic Input to Left/Right Balance Output 79 dB (max gain)
Line Input Gain Adjustment Range: -16 dB to 40 dB
Line Input to Left/Right Balance Output 60 dB (max gain)
Stereo 5/6 1/4" Gain Adjustment Range: O to +18 dB
Stereo 5/6 1/4"to Left/Right Output 42 dB (max gain)
Stereo 5/6 3.5mm / RCA Gain Adjustment Range: O to +28 dB
Stereo 5/6 3.5mm / RCA to Left/Right Output: 47 dB (max gain)
Stereo 9/10 Gain Adjustment Range: O to +18 dB
Stereo 9/10 to Left/Right Output 28 dB (max gain)
Mic Input to Left/Right Output, Max Input Gain 14 Hz to 25 kHz +0 dB/-1 dB
Mic Input to Left/Right Output, input gain 12:00 9.5 Hz to 29 kHz +0 dB/-0.8 dB
<0.006% Typical, Mic to Left/Right Output (22 Hz to 22 kHz BW)
Output Residual Noise S/N Ratio (Ref: +4dBu) Test Conditions
Master Left/Right -97 dBu 101 dB Master Fader Down, Channel Levels Down
-90 dBu 94 dB Master Fader Nominal, Channel Levels Down
-83 dBu 87 dB Master Fade Nominal, Channel Faders Nominal,
Panned Odd Channels (left), Even Channels
(right)
Monitor Send -95 dBu 99 dB All controls o
-80 dBu 84 dB All channel sends nominal, masters nominal
(Hum and noise measurements: 22 Hz to 22 kHz BW)
-128 dBu (input terminated with 150 ohms, bandwidth 20 kHz)
