PV®6 and PV®6BT Rear Panel
POWER
ON
DIGITAL AUDIO
PORT
COMPUTER
37 38 39
28
29
30
DC POWER INLET
Use to connect the included power supply. Be sure the power supply is connected to the PV®10 before connecting to a power source.
Use 15VDC, 1A adapter only. Replace only with Peavey part number 30908119.
POWER SWITCH
is is the main power switch.
USB PORT TYPE B
e USB port is used to connect the PV® Series USB mixer to a computer for recording or playing back digital audio to/from your computer.
e USB port sends the mixer’s main/tape stereo out to the computer. e USB port receives digital audio from the computer; it can then be
assigned through the USB TO Main switch ({18}, PV6; {21}, PV6BT) to the main le/right output, if the computer is being used for playback
only. For recording, use the USB TO CONTROL ROOM control ({17}, PV6; {20}, PV6BT), to avoid creating a loop. Compatible with Win-
dows® Vista, Windows 7, & Windows 8, Mac OS X® 10.0 or later, and iOS devices.
