Gain
Frequency Response
Total Harmonic Distortion
Hum and Noise
Equivalent Input Noise (EIN)
Mic Input Gain Adjustment Range: +4 dB to +59 dB
Mic Input to Left/Right Balance Output 79 dB (max gain)
Line Input Gain Adjustment Range: -15 dB to 40 dB
Line Input to Left/Right Balance Output 60 dB (max gain)
Stereo 3/4 Gain Adjustment Range: O to +19 dB
Stereo3/4 to Left/Right Output 39 dB (max gain)
3.5mm Input Gain Adjustment Range: O to +30 dB
3.5mm Input to Left/Right Output 51 dB (max gain)
Stereo Line 5/6 Gain Adjustment Range: O to +18 dB
Stereo 5/6 to Left/Right Output 28 dB (max gain)
Mic Input to Left/Right Output 10 Hz to 20 kHz +0 dB/-1 dB
<0.006% Typical (22 Hz to 22 kHz BW)
-126 dBu (input terminated with 150 ohms, bandwidth 20 kHz)
Output Residual Noise S/N Ratio (Ref: +4dBu) Test Conditions
Master Left/Right -97 dBu 101 dB Master Fader Down, Channel Levels Down
-92 dBu 96 dB Master Fader Nominal, Channel Levels Down,
Efx muted
-82 dBu 86 dB Master Fade Nominal, Channel Faders Nominal,
Panned Odd Channels (left), Even Channels
(right)
(Hum and noise measurements: 22 Hz to 22 kHz BW)
RCA Gain Adjustment Range: O to +29 dB
RCA to Left/Right Output 39 dB (max gain)
