Crossover Slopes: 24 dB/octave (4th order) low pass, 24dB/octave (fourth order) high pass, both with
staggered poles and driver EQ.
Input Connections:
One combo female XLR and 1/4" phone jack providing balanced line-level operation from the 1/4” jack section,
and high-output dynamic microphone operation from the XLR section.
Output Connections: One male XLR and one 1/4” phone jack. The Thru jacks are intended for the use of linking
multiple PVXp
™
15 enclosures in a line or to provide a feed to a powered subwoofer, or other electronics that
needs to receive a full range version of the input signal.
Enclosure Materials & Finish: Black ABS plastic with textured surface, black powder-coated perforated grille.
Also available in white.
Mounting provisions: Unit has two sets of two M10 inserts, one pair on the top, and one pair on the bottom.
Additional mounting points are a set of four M8 inserts on the top, and a set of four on the right side in the
handle recess, and a set of four on the bottom, which use the Peavey Versamount
™
70+ mounting bracket. Four
rubber feet provide vibration free floor or stage use, and a molded-in stand mounting cup is on the bottom.
Dimensions (H x W x D):
Front: 28.25 in. x 18.90 in. x 18.71 in 718 mm x 480 mm x 475 mm
Rear: 26.25 in. x 10.25 in. x 18.71 in. 667 mm x 260 mm x 475 mm
Net Weight:
51 lbs. (23.2 kg)
ELECTRONICS AND AMPLIFIER SPECIFICATIONS:
Internal power amplifiers (@120 VAC line):
Total of 800 watts peak available power
Woofer - 650 watts peak available power
Continuous Power*: 325 watts @ less than 1% distortion
Tweeter - 150 watts peak available power
Continuous Power: 75 watts @ less than 1% distortion.
* Before thermal pull-back activates.
Electronic Input Impedance (Nominal):
Line: 2.2 k ohms balanced (1/4"), 10 k ohms unbalanced 1/4"
Mic: 2.2 k ohms balanced (XLR) No phantom power available.
Input Sensitivity for Full Output (Level full CW): 1/4” TRS Phone jack – 0.54 V RMS, XLR jack – 0.12 V RMS
Infrasonic filter protection: 36 dB/octave roll-off
Nominal Amplifier Frequency Response: +0, -3 dB from 20 Hz to 20 kHz
Hum and Noise: Greater than 90 dB below rated power
DDT
™
Dynamic Range: Greater than 21 dB
THD and IM: Typically less than 0.5 %
Damping Factor: Greater than 100 @ 1000 Hz, 8 Ohms
Power requirements of Peavey PVXp
15 System: Nominal 370 Watts, 100-120 VAC 50-60 Hz
