Pecron E2000 LFP - SOLAR PANEL CONNECTION EXAMPLES; 400 W (2 x200 W) Series Connection; 400 W (2 x200 W) Parallel Connection

support@pecron.com
USING SOLAR PANELS TO CHARGE THE E2000 LFP
Using the pecron 200W /36V*2 （400W）to charge the E2000 LFP
Using the pecron 200W /36V*2 （400W）to charge the E2000 LFP
MC4 Solar Charging Cable*1
※ 36V is the operating voltage of the solar panels
pecron 200W*2
36V
36V
72V
MC4 Solar Charging Cable*2
※ 36V is the operating voltage of the solar panels
pecron 200W*2
36V
36V
36V
36V
