Pecron E3600 LFP - Page 13

DC INPUT
32V~150V
1200W(MAX)*2
12V~30V
150W(MAX)
DC INPUT
32V~150V
1200W(MAX)*2
12V~30V
150W(MAX)
DC INPUT
32V~150V
1200W(MAX)*2
12V~30V
150W(MAX)
USING SOLAR PANELS TO CHARGE THE E3600 LFP
support@pecron.com
Charging the E3600 LFP with one solar panel
MC4 Solar Charging Cable *1
※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be
less than 150V, and the VMP should be greater than 32V.
MC4 Solar Charging Cable *1
Use two solar panels in series to charge the E3600 LFP
※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be
less than 75V, and the VMP should be greater than 16V.
