DC INPUT
32V~150V
1200W(MAX)*2
12V~30V
150W(MAX)
support@pecron.com
Use three solar panels in series to charge the E3600 LFP
(It is recommended to use solar panels with same specifications for optimal power.)
MC4 Solar Charging Cable *1
※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be
less than 50V, and the VMP should be greater than 11V.
