DC INPUT
32V~150V
1200W(MAX)*2
12V~30V
150W(MAX)
AC OUTPUT - 3600W
18W
18W
USB
12V
12V-10A12V-5A
12V-30A
DC OUTPUT
DC
E3600
AC
100W 18W
18W 18W
support@pecron.com
HOW TO USE THE E3600 LFP
press and hold to turn on / off DC / USB / Wireless Charger
press and hold to turn on / off AC
(Please turn off the AC function if there is no AC load on the unit)
5521 *1
MJ32 *2 Cascade with max 4 pieces of EP3000-48V
3 5
4
2 1
12V~30V Max 7A Max 150W
DC INPUT
EXTRA BATTERY PORT
MJ25 (3+2) *1
XT60-M *2
AC INPUT
100Vac~120Vac 50/60HZ
1800W Max (Charging cable with 15A）
3200W Max (Charging cable with 30A）
32V~150V Max 20A Max 1200W*2
