Pecron E600 LFP - Technical Specifications; General Device Specifications; Output Port Specifications; Input Port Specifications

INPUT SPECS
DC Charging(32V~95V)
Max 400W
5521*1
DC Charging(12V~18V)
Max 100W
GX16MF*1
SPECIFICATIONS
LiFePO4 Battery
Retain 80%+
Original Capacity
At 3500 Cycles
Dimension
L11.7*W7.8*H8.5 in
L298*W199*H215
mm
Capacity
Battery Type
Net Weight
Around 20lb
Around 9.4kg
614Wh
(25.6V24Ah)
Protections
Over-Voltage,
Overheat,
Overload,
Short-Circuit,
Self-Recovery
Temperature
0℃~45℃/32°F~113°F
(Charging)
-20℃~45℃/-4°F~113°F
(Discharging)
Charging Time
It can be fully recharged
in just 1.5 hours by
solar panels, and 2.2
hours by AC charger
OUTPUT SPECS
AC Out*3
USB-A*2
(5V,9V,12V,
Max 18W)*1
(5V,9V,12V,20V,
Max 100W)*1
USB-C*2
Cigar Port*1
Max 15W
Wireless Charger*1
DC 5525 Output*2
(5V,9V,12V,
Max 18W)*2
DC 12V 10A
DC 12V 5A
E600
LFP
Pure sine wave
100V~120V
Rated 1200W
support@pecron.com
( Do not support charging from both input ports at the same time.)
