Pecron E600 LFP - Using Solar Panels for Charging; DC5521 Charging Port Solar Input; GX16 MF-5 Charging Port Solar Input

E600
LFP
USING SOLAR PANELS TO CHARGE THE E600 LFP
1. DC5521 Charging Port: PV/DC 12V~18V, 100W maximum; VOC(open circuit voltage) of solar panel must be less
than 25V;
2. GX16MF-5 Charging Port: PV(operating voltage) range 32V~95V, 400W maximum; VOC(open circuit voltage) of solar
panel/array must be less than 95V, otherwise, it will damage the unit! Do not wire more than two 36V solar panels in
series. (36V stands for Vmp, the operating voltage, of the solar panel)
3. If you have any questions, Please feel free to contact us：support@pecron.com
DC5521 Charging Port:
PV12V~18V-100W Maximum Input
GX16MF-5 Charging Port:
PV32~95V-400W Maximum Input
support@pecron.com
( Do not support charging from both input ports at the same time.)
