HOW TO CHARGE THE EB3000-24V BATTERY PACK BY VEHICL
Car charge cable with GX16MF-5 connector
SOLAR CHARGE TIME
MC4 Solar
Charging Cable
pecron 200W
Note: The above data comes from Pecron＇s laboratory. Actual charging time depends on
the weather conditions.
200W(×1)
19~20 Hours
Recommended
400W(×2)
10~11 Hours
Recommended
USING SOLAR PANELS TO CHARGE THE EB3000-24V
GX16MF-5 Charging Port: PV(operating voltage) range 12V~95V, 400W maximum; VOC(open circuit voltage) of solar
panel/array must be less than 95V, otherwise, it will damage the unit! Do not wire more than two 36V(AKA 24V) solar
panels in series.(18V~36V stands for Vmp, the operating voltage, of the solar panel)
GX16MF-5 Charging Port:
PV12~95V-400W Maximum Input
