Peerless Pump AEF - Page 11

P
P
TM060222
Fig. Parallel misalignment
TM060223
Fig. Using a dial indicator to check alignment
3.5.3.2 Coupling gap settings, Falk/Clarke/Dodge
Coupling
Max.
RPM
Parallel Angularity Weight Torque
[in
(mm)]
[in (mm)] [lb (kg)]
[lb-in
(Nm)]
1020 4500
0.006
(0.15)
0.003
(0.08)
4.2
(1.9)
460 (52)
1030 4500
0.006
(0.15)
0.003
(0.08)
5.7
(2.6)
1320
(149)
1040 4500
0.006
(0.15)
0.003
(0.08)
7.4
(3.4)
2200
(249)
1050 4500
0.008
(0.2)
0.004
(0.1)
12 (5.4)
3850
(435)
1060 4350
0.008
(0.2)
0.005
(0.13)
16 (7.3)
6050
(684)
1070 4125
0.008
(0.2)
0.005
(0.13)
23
(10.4)
8800
(994)
1080 3600
0.008
(0.2)
0.006
(0.15)
39
(17.7)
18150
(2051)
1090 3600
0.008
(0.2)
0.007
(0.18)
56
(25.4)
33000
(3729)
1100 2440
0.01
(0.25)
0.008
(0.2)
93
(42.2)
55550
(6276)
1110 2250
0.01
(0.25)
0.009
(0.23)
120
(54.4)
82500
(9321)
1120 2025
0.011
(0.28)
0.01
(0.25)
179
(81.2)
121000
(13671)
1130 1800
0.011
(0.28)
0.012
(0.3)
266
(120.7)
176000
(19885)
1140 1650
0.011
(0.28)
0.013
(0.33)
392
(177.8)
253000
(28585)
3.5.3.3 Coupling gap and maximum misalignment, KTR
ROTEX
size
E distance
Max.
parallel
Max.
angularity
Max. axial
[in (mm)] [in (mm)] [in (mm)] [in (mm)]
14 0.51 (13)
0.006
(0.15)
1.1 (28)
-0.02 (-0.5)
+ 0.04 (1)
19 0.63 (16)
0.007
(0.18)
1 (25)
-0.02 (-0.5)
+ 0.05 (1.3)
24 0.71 (18) 0.008 (0.2) 0.08 (2)
-0.02 (-0.5)
+ 0.06 (1.5)
28 0.79 (20.1)
0.009
(0.23)
0.09 (2)
-0.03 (-0.8)
+ 0.06 (1.5)
38 0.94 (23.9) 0.01 (0.25) 0.09 (2)
-0.03 (-0.8)
+ 0.07 (1.8)
42 1.02 (25.9)
0.011
(0.28)
1 (25)
-0.04 (-1) +
0.08 (2)
48 1.1 (27.9)
0.013
(0.33)
1.1 (28)
-0.04 (-1) +
0.08 (2)
55 1.18 (30)
0.014
(0.36)
1.1 (28)
-0.04 (-1) +
0.09 (2.3)
65 1.38 (35.1)
0.015
(0.38)
1.1 (28)
-0.04 (-1) +
0.1 (2.5)
75 1.57 (39.9)
0.017
(0.43)
1.1 (28)
-0.06 (-1.5)
+ 0.12 (3)
90 1.77 (45)
0.018
(0.46)
1.2 (30)
-0.06 (-1.5)
+ 0.13
(3.3)
100 1.97 (50)
0.019
(0.48)
1.2 (30)
-0.06 (-1.5)
+ 0.15
(3.8)
110 2.17 (55.1) 0.02 (0.51) 1.2 (30)
-0.08 (-2) +
0.17 (4.3)
125 2.36 (59.9)
0.021
(0.53)
1.2 (30)
-0.08 (-2) +
0.18 (4.6)
140 2.56 (65)
0.022
(0.56)
1.2 (30)
-0.08 (-2) +
0.2 (5.1)
160 2.95 (74.9)
0.022
(0.56)
1.2 (30)
-0.1 (-2.5) +
0.22 (5.6)
180 3.35 (85.1)
0.024
(0.61)
1.2 (30)
-0.12 (-3) +
0.25 (6.4)
E
TM061156
Fig.
E (Distance)
11
